CP Pistons CPN Piston Ring Set 100 mm (3.937 in) Bore, 1.0/1.2/2.8 mm
CPN-3937
$30.25 USD
CP Pistons' CPN piston ring set is sized for a 100 mm (3.937 in) bore. It pairs a 1.0 mm top ring, a 1.2 mm second ring and a 2.8 mm oil ring. CP designs the CPN sets as high-strength, low-tension rings for engines with high cylinder pressures.
Key features
- Gas nitrided steel top ring: a thin 1.0 mm face for sealing under high cylinder pressure.
- Napier-style second ring: a taper hook groove design that helps scrape oil off the cylinder wall.
- Low-tension flex vent oil ring: a 2.8 mm ring that seals with minimal drag.
- Nikasil compatible: CP lists the CPN sets as compatible with newer cylinder materials such as Nikasil.
Specifications
| Brand | CP Pistons |
|---|---|
| Part number | CPN-3937 |
| Bore | 100.0 mm (3.937 in) |
| Top ring | 1.0 mm, gas nitrided steel |
| Second ring | 1.2 mm, taper hook groove Napier |
| Oil ring | 2.8 mm, low-tension flex vent |
Fitment
Universal fit. Check the specifications above against your application.
