Eagle connecting rod for Honda B16 – CRS5290HXD-1

Eagle Extreme Duty 4340 H-Beam Connecting Rod, Single, for Honda B16

CRS5290HXD-1
$253.99 USD

Eagle's Extreme Duty forged 4340 H-beam connecting rod is a single replacement rod for the Honda B16, part number CRS5290HXD-1. It suits B16 builders who need to replace one rod, or add to a set, and want the polished Extreme Duty finish. Eagle recommends it for the most extreme applications.

Key features

  • Forged 4340 steel H-beam: made from a two-piece forging, then fully machined.
  • Shot-peened and polished: the polished surface is what sets Extreme Duty apart from Eagle's standard H-beam rod.
  • Held to exact tolerances: sizing is controlled so the rod matches the rest of your rotating assembly.
  • Bushed for a full-floating piston pin: 0.826 in. pin size and 0.785 in. pin end width.
  • ARP Custom Age 625+ bolts: Eagle specifies 3/8 in. bolts for this rod. Torque to 60 ft-lbs with ARP moly lube only.

Specifications

Brand Eagle
Part number CRS5290HXD-1
Engine Honda B16
Material Forged 4340 steel
Beam style H-beam
Quantity Single rod
Center-to-center length 5.29 in.
Pin size 0.826 in.
Pin end width 0.785 in.
Rod journal 1.771 in.
Housing bore 1.89 in.
Big end width 0.935 in.
Typical weight 560 g
Bolts 3/8 in. ARP Custom Age 625+

Forged rods only go as far as the block holding them. An EPOXY54 kit for the B16 gives the block closed-deck strength without machining, with 21,000 psi compressive strength and a DIY install in 5 steps.

Fitment

Fits Honda B16. Match by part number CRS5290HXD-1 before ordering.

WARNING: This product can expose you to chemicals known to the State of California to cause cancer and/or reproductive harm. For more information, go to www.P65Warnings.ca.gov.

CRS5290HXD-1
