Eagle Extreme Duty H-Beam Connecting Rod (Single) 5.984 in for Honda K24
Eagle's Extreme Duty forged 4340 H-beam connecting rod is a single 5.984 in rod for the Honda K24. Sold one at a time, it suits a K24 builder who needs to replace a single rod or assemble a set to a chosen weight. Eagle recommends it for the most extreme applications.
Key features
- Forged 4340 steel H-beam: forged from a two-piece forging, the way Eagle builds its H-beam rods.
- Finished surface: fully machined, shot-peened and polished.
- 3/8 in ARP Custom Age 625+ bolts: Eagle specifies ARP Custom Age 625+ cap bolts for this rod. Torque them to 60 ft-lbs with ARP moly lube only.
- Bushed for a full-floating pin: the pin end takes a 0.866 in piston pin.
- Held to exact tolerances: Eagle sizes the rod to tight tolerances, so it arrives ready for assembly.
Specifications
| Brand | Eagle |
|---|---|
| Part number | CRS5984KXD-1 |
| Engine | Honda K24 |
| Material | Forged 4340 steel |
| Beam style | H-beam |
| Quantity | Single rod |
| Center-to-center length | 5.984 in (152 mm) |
| Pin size | 0.866 in |
| Pin end width | 0.779 in |
| Big end width | 0.779 in |
| Housing bore | 2.008 in |
| Rod journal | 1.889 in |
| Bolts | 3/8 in ARP Custom Age 625+ |
| Typical weight | 555 g |
Forged internals only go as far as the block holding them. An EPOXY54 kit for the K24 gives the block closed-deck strength without machining, with 21,000 psi compressive strength and a DIY install in 5 steps.
Fitment
Fits Honda K24. Match by part number CRS5984KXD-1 before ordering.
