Eagle Extreme Duty 4340 H-Beam Connecting Rod (Single) 5.137 in for Subaru EJ20 and EJ25
Eagle's Extreme Duty H-beam connecting rod is a single forged 4340 steel replacement for the Subaru EJ20 and EJ25, with a 5.137 in center-to-center length. Eagle recommends it for the most extreme applications. Buy one to replace a single rod, or order several to build a full set.
Key features
- Two-piece forging: the rod is forged in two pieces, then fully machined, shot-peened and polished.
- ARP Custom Age 625+ bolts: 3/8 in fasteners. Eagle says to torque them to 60 ft-lbs using ARP moly lube only.
- Bushed for a full-floating pin: the small end is bushed for a full-floating piston pin.
- Weight: typical weight is 530 g. Eagle's page says to specify the weight you need when ordering.
Specifications
| Brand | Eagle |
|---|---|
| Part number | CRS5137SXD-1 |
| Engine | Subaru EJ20, EJ25 |
| Material | Forged 4340 steel |
| Beam | H-beam |
| Rod length | 5.137 in (center to center) |
| Wrist pin | 0.906 in |
| Quantity | 1 (single rod) |
| Rod journal | 2.047 in |
| Housing bore | 2.165 in |
| Big end width | 0.842 in |
| Pin end width | 0.842 in |
| Typical weight | 530 g |
| Bolts | 3/8 in ARP Custom Age 625+ |
Forged internals only go as far as the block holding them. An EPOXY54 kit for the EJ20 gives the block closed-deck strength without machining, with 21,000 psi compressive strength and a DIY install in 5 steps.
Fitment
Fits Subaru EJ20 and EJ25. Match by part number CRS5137SXD-1 before ordering.
