Ferrea single valve spring for BMW N54 – S10158

Ferrea Turbo PAC Single Valve Spring Set of 24 for BMW N54

Sale price  $522.72 USD Regular price  $580.80 USD
Skip to product information
Ferrea single valve spring for BMW N54 – S10158

Ferrea Turbo PAC Single Valve Spring Set of 24 for BMW N54

S10158
Sale price  $522.72 USD Regular price  $580.80 USD

Ferrea's S10158 single valve spring set gives the BMW N54 all 24 springs it needs, one for each valve on the DOHC 24-valve head. They are made from Turbo PAC Enhanced Alloy. This set is for N54 builders who are replacing the valvetrain and want to match Ferrea's titanium retainers.

Key features

  • Turbo PAC Enhanced Alloy: a single-spring design in the alloy Ferrea specifies for this part number.
  • Set of 24: covers every valve on the N54 head, so you don't have to count out springs.
  • 170 lbs open pressure: 70 lbs at 36.5 mm seat height and 170 lbs at 26.5 mm open height, with a rate of 254 lbs per inch.
  • Matched retainers: requires Ferrea titanium retainers E11130 (exhaust) and E11131 (intake), plus the factory spring seat locator and valve hat seal.
  • Lift limit: Ferrea warns that net valve lift must stay within the recommended figure, because of seal-to-retainer clearance. Max net lift is 12.5 mm.

Specifications

Brand Ferrea
Part number S10158
Engine BMW N54
Type Single spring
Material Turbo PAC Enhanced Alloy
Quantity Set of 24
Outside diameter 22.38 mm
Inside diameter 15.52 mm
Seat pressure 70 lbs @ 36.5 mm
Open pressure 170 lbs @ 26.5 mm
Spring rate 254 lbs per inch
Coil bind 23.15 mm
Max net lift 12.5 mm

Fitment

Fits BMW N54. Match by part number S10158 before ordering.
